Feautures :
VFD COMFORT DISPLAY, resolution 0.01 °C.
LCD DIALOG DISPLAY backlit for convenient interactive operation.
Keypad for setpoints, warning/safety values and menu functions.
ICC (Intelligent Cascade Control), self-optimizing temperature control.
TCF Temperature Control Features to optimize the control behaviour.
ATC3 3-Point-Calibration.
Pt100 External sensor connection for measurement and control.
SMART PUMP, electronically adjustable pump stages.
Early warning system for low liquid level (DBGM 203 06 059.8).
Adjustable high temperature cut-out, visible via display.
RS232/RS485 interface for online communication.
Integrated programmer for 6 x 60 program steps.
Connections for solenoid valve and HSP booster pump.
Proportional cooling control.
Active Cooling Control.
| Working temperature range | -90 ... 150 °C |
| Temperature control | ICC |
| Temperature stability | ±0.05 °C |
| Display | VFD + LCD |
| Display resolution | 0.01 °C |
| Integrated programmer | available |
| Heater capacity | 3000 W |
| Cooling capacity | 20°C(1800 W), 0°C(1700 W), -20°C(1600 W), -40°C(1350 W), -60°C(750 W), -80°C(150 W) |
| Refrigerant | R404a + R23 |
| Pump capacity | Pressure: 0.7 bar |
| Suction: 0.4 bar | |
| Flow rate: 22 - 26 l/min | |
| Digital interfaces | RS232, RS485, optional Profibus |
| External Pt100 sensor connection | available |
| Bath opening / bath depth (W x L / D) | dia = 7 / 20 cm |
| Filling volume | 22 Liters |
| Dimensions (W x L x H) | 59 x 76 x 116 cm |
| Weight | 214 kg |
| Ambient temperature | 5…40 °C |
| Classification according to DIN 12876-1 | 3 (FL) |
