Feautures :
MULTI-DISPLAY (LED) for actual and setpoint values, warning/safety functions and pump stage.
Keypad for setpoints, warning/safety values and menu functions.
PID2 temperature control with drift compensation.
ATC3 3-Point-Calibration.
Early warning system for low liquid level (DBGM 203 06 059.8).
Adjustable high temperature cut-out, visible via display.
RS232 interface for online communication.
SMART PUMP, electronically adjustable pump stages.
| Working temperature range | 20 ... 200 °C |
| Temperature control | PID |
| Temperature stability | ±0.01 °C |
| Display | LED |
| Display resolution | 0.1 °C (-9.99 ... 99.99 °C) / 0.1 °C |
| Integrated programmer | not available |
| Heater capacity | 2000 W |
| Digital interfaces | RS232 |
| Pump capacity | Pressure: 0.23 ... 0.45 bar |
| Flow rate: 11-16 l/min | |
| Dimensions (W x L x H) | 13 x 15 x 33 cm |
| Weight | 4 kg |
| Ambient temperature | 5…40 °C |
| Classification according to DIN 12876-1 | 3 (FL) |
