Feautures :
MULTI-DISPLAY (LED) for actual and setpoint values, warning/safety functions and pump stage.
Keypad for setpoints, warning/safety values and menu functions.
PID2 temperature control with drift compensation.
ATC3 3-Point-Calibration.
Early warning system for low liquid level (DBGM 203 06 059.8).
Adjustable high temperature cut-out, visible via display.
RS232 interface for online communication.
| Working temperature range | 20 ... 60 °C |
| Temperature control | PID |
| Temperature stability | ±0.02 °C |
| Display | LED |
| Display resolution | 0.1 °C |
| Integrated programmer | not available |
| Heater capacity | 2000 W |
| Digital interfaces | RS232 |
| Pump capacity | Pressure: 0.12 bar |
| Flow rate: 10 l/min | |
| Bath opening / bath depth (W x L / D) | 12 x 24 / 15 cm |
| Filling volume | 5 Liters |
| Dimensions (W x L x H) | 14 x 40 x 35 cm |
| Weight | 5.3 kg |
| Ambient temperature | 5…40 °C |
| Classification according to DIN 12876-1 | 1 (NFL) |
