Feautures :
VFD COMFORT DISPLAY.
LCD DIALOG DISPLAY backlit for convenient interactive operation.
Keypad for setpoints, warning/safety values and menu functions.
ICC (Intelligent Cascade Control), self-optimizing temperature control.
TCF Temperature Control Features to optimize the control behaviour.
ATC3 3-Point-Calibration.
Pt100 External sensor connection for measurement and control.
SMART PUMP, electronically adjustable pump stages.
Early warning system for low liquid level (DBGM 203 06 059.8).
Adjustable high temperature cut-out, visible via display.
RS232/RS485 interface for online communication.
Integrated programmer for 6 x 60 program steps.
Connections for solenoid valve and HSP booster pump.
| Working temperature range | 20 ... 300 °C |
| Temperature stability | ±0.01 °C |
| Display resolution | 0.01 °C |
| Integrated programmer | 6x60 steps |
| Temperature Display | VFD, LCD |
| Heating capacity | 3000 W |
| Pump capacity | Pressure: 0.4 - 0.7 bar |
| Suction: 0.2 - 0.4 bar | |
| Flow rate: 22-26 l/min | |
| Bath opening / bath depth (W x L / D) | 22 x 30 / 20 cm |
| Pump connections/td> | M16x1 |
| Barbed fittings diameter | inner dia. 8 / 12 mm |
| Filling volume | 26 Liters |
| External Pt100 sensor connection | integrated |
| Digital interfaces | RS232, RS485 |
| Ambient temperature | 5…40 °C |
| Dimensions (W x L x H) | 36 x 61 x 47 cm |
| Weight | - |
| Classification according to DIN 12876-1 | Classification III (FL) according to DIN 12876-1 |
| Included with each unit | 2 each barbed fittings for tubing 8 and 12 mm inner dia. (pump connections M16x1 female) |
| Cooling coil | integrated |
| Bath tank | Stainless steel |
