Feautures :

Extremely time efficient.

Measuring time of just 1 second: the fastest polarimeter in the world!

Utmost accuracy and resolution.

The convenient touchscreen enables complete sample and user management directly on the device. An integrated SQL database for saving data is also included. The polarimeters can be connected to a PC via an Ethernet interface or integrated into an existing network.

Complete GLP capability.



Model P8000 P8000-T P8100 P8100-T
Measuring method Optical rotation, int. sugar scale, concentration, spec. rotation, user-defined Optical rotation, int. sugar scale, concentration, spec. rotation, user-defined Optical rotation, int. sugar scale, concentration, spec. rotation, user-defined Optical rotation, int. sugar scale, concentration, spec. rotation, user-defined
Measuring range ±90° ±90° ±90° ±90°
±259 °Z ±259 °Z ±259 °Z ±259 °Z
0 – 99.9 g/ml 0 – 99.9 g/ml 0 – 99.9 g/ml 0 – 99.9 g/ml
Measuring units Angle [°, °Z] Angle [°, °Z] Angle [°, °Z] Angle [°, °Z]
conc. [g/100 ml] conc. [g/100 ml] conc. [g/100 ml] conc. [g/100 ml]
user defined user defined user defined user defined
Resolution 0.001° 0.001° 0.001° 0.001°
0.01 °Z 0.01 °Z 0.01 °Z 0.01 °Z
0.1 g/ml 0.1 g/ml 0.1 g/ml 0.1 g/ml
Accuracy ±0.003° ±0.003° ±0.003° ±0.003°
±0.01 °Z ±0.01 °Z ±0.01 °Z ±0.01 °Z
±0.5 g/100 ml ±0.5 g/100 ml ±0.5 g/100 ml ±0.5 g/100 ml
Reproducibility 0.002° 0.002° 0.002° 0.002°
Measuring time ±90° 1 s 1 s 1 s 1 s
Light source 1 LED with filter 1 LED with filter 1 LED with filter 1 LED with filter
Wavelength 589 nm 589 nm 589 nm 589 nm
others optional others optional others optional others optional
Wavelength selection One fixed wavelength One fixed wavelength One fixed wavelength One fixed wavelength
Connection for temperature sensor Special tube with PT100 temperature sensor required Special tube with PT100 temperature sensor required Special tube with PT100 temperature sensor required Special tube with PT100 temperature sensor required
Temperature measurement 0 – 99.9 °C 0 – 99.9 °C 0 – 99.9 °C 0 – 99.9 °C
Temperature resolution 0.1 °C 0.1 °C 0.1 °C 0.1 °C
Temperature accuracy ±0.2 °C ±0.2 °C ±0.2 °C ±0.2 °C
Temperature reading point Tube Tube Tube Tube
Temperature control - PT31 Peltier thermostat (water) with fast closure system - PT31 Peltier thermostat (water) with fast closure system
Range of temperature control - 15 – 40.0 °C - 15 – 40.0 °C
Accuracy of temperature control - ±0.2 °C - ±0.2 °C
Max. length of tube 220 mm 220 mm 220 mm 220 mm
Sensitivity min 0.1 % (OD3) min 0.1 % (OD3) min 0.1 % (OD3) min 0.1 % (OD3)
Calibration Automatic (menu-driven) Automatic (menu-driven) Automatic (menu-driven) Automatic (menu-driven)
Display LCD TFT 5.7 “ LCD TFT 5.7 “ LCD TFT 5.7 “ LCD TFT 5.7 “
640x480 pixel 640x480 pixel 640x480 pixel 640x480 pixel
color display (VGA) color display (VGA) color display (VGA) color display (VGA)
Operation Touchscreen Touchscreen Touchscreen Touchscreen Touchscreen
Measured data storage 999 measurements 999 measurements 999 measurements 999 measurements
Interfaces RS-232 (printer) RS-232 (printer) RS-232 (printer) RS-232 (printer)
USB (data export, firmware updates) USB (data export, firmware updates) USB (data export, firmware updates) USB (data export, firmware updates)
Ethernet (LIMS, remote monitoring) Ethernet (LIMS, remote monitoring) Ethernet (LIMS, remote monitoring) Ethernet (LIMS, remote monitoring)
Operating voltage 90 – 250 V 90 – 250 V 90 – 250 V 90 – 250 V
50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Dimensions in cm 64.5 x 20.0 x 36.0 64.5 x 20.0 x 36.0 64.5 x 20.0 x 36.0 64.5 x 20.0 x 36.0
Weight 28 kg 28 kg 28 kg 28 kg
