Feautures :
With a simple, intuitive touchscreen all results and user management can be operated on the device.
The unit incorporates an integrated SQL database, for storing data, and allows for access via a network or standalone PC.
The DR6000 has an integrated Peltier thermostat for efficient temperature control, allowing very short measuring times at maximum accuracy.
Easy cleaning of the probe.
Interface and software package for full GLP compliance.
| Measurement modes | Single, Interval |
| Scales | Preset standard scales: Refractive Index [nD], %Brix saccharose, inverted sugar, glucose, fructose, Temperature compensated [nD], Temperature compensated [%Brix]. |
| User defined scales can be initialised. | |
| Calibration | Automatic (menu-driven), manufacturer´s calibration with up to 30 sampling points, user defined 1-point-calibration |
| Measurement time | ~4 s |
| Prism | Sapphire |
| Illumination | LED 590 nm (est. life: >100.000 hours) |
| Housing | Cast aluminium, powder-coated |
| Analysis basin | Stainless steel |
| Display | LCD TFT 5.7 ", 640x480 pixel color display (VGA) |
| Operation | Touchscreen |
| Measured data storage | 999 measurements |
| Interface | RS-232 (printer) |
| USB (data export, firmware updates) | |
| Ethernet (LIMS, remote monitoring) | |
| Working voltage | 90–250 V |
| 50/60 HzW | |
| Protection class | IP65 for analysis basin |
| Temperature measurement | 5–90 °C |
| Temperature resolution | 0.1 °C |
| Temperature measurement accuracy | ±0.05 °C |
| Temperature compensation | ICUMSA, User defined 3-Point |
| Temperature sensor | PT100 Sensor |
| Sample temperature | 10–80 °C |
| Ambient temperature | 15–35 °C |
| Temperature control (except T-Models) | Thermostat connections |
| Dimensions in cm | 21.5 x 15 x 34.5 |
| Weight | 5 kg |
